DESCRIPTION:
Expanded metal lath(wall plaster mesh) is manufactured from pre-galvanised steel to BS EN 10142 quality, this metal lath is to avoid the cracking on wall due to different contraction rate of concrete and plaster material. Use with galvanised angle bead, galvanised stop bead, plasterer can be sure of perfect workmanship and quality of plastering job.
Specifications:
1. Regular diamond metal lath: regular diamond metal lath is a multi-purpose plaster base and reinforcement, it is ideal as a plaster base and reinforcement for all types
| Code | Weight | Sheet size | Pcs/Bdl | Pcs/Plt |
| MG-RML | 1.7lbs | 27" x 96" | 10 | 500 |
| MG-RML | 2.5lbs | 27" x 96" | 10 | 500 |
| MG-RML | 3.4lbs | 27" x 96" | 10 | 500 |
2. Slef-furring metal lath: Dimples or embossed a “V”groove hold the lath appropriately 1/4’’ away from the wall, allow the plaster to fill up the space between, insuring it is embedded.
| Code | Weight | Sheet size | Pcs/Bdl | Pcs/Plt |
| MG-RML | 1.7lbs | 27’’ x 97’’ | 10 | 250 |
| MG-RML | 2.5lbs | 27’’ x 97’’ | 10 | 250 |
| MG-RML | 3.4lbs | 27’’ x 97’’ | 10 | 250 |
3. Paper backed metal lath: Paper backed metal lath is regular or self-furring, which offset asphalt, saturated Kraft building paper will be used, It provides protection against wet areas during stucco curing.
| Code | Weight | Sheet size | Pcs/Bdl | Pcs/Plt |
| MG-RML | 1.7lbs | 27" x 97" | 10 | 250 |
| MG-RML | 2.5lbs | 27" x 97" | 10 | 250 |
| MG-RML | 3.4lbs | 27" x 97" | 10 | 250 |
